Specifications:
1.Motor diameter: 15 MM
2.Output gear outer diameter: 7 MM (12 teeth, 0.5 module)
3.Gearbox reduction ratio: 1: 51.4 (approximately)
(Approximately 1028 pulse,output shafts rotate 360 degrees)
4.Step angle: The motor is 18 degrees, and the output shaft is about 0.35 degrees.
5.Stepping motor: two-phase four-wire
6.Wire connect: (A : red line, A-: white line. B : black line, B-: brown line)
7.Phase resistance: 31.3 ohms (6V short-circuit current 0.19 A)
8.Cable length: 65 MM
9.Weight: 14 g
Package includes:
1PCS * Gear Motor
